99.08%
Max. Efficiency
-
208kW@50°C
228kW@40°C
250kW@30°CNominal Output Power
-
IP66
IP Rating
-
C5
Corrosion Prevention
Product Introduction
The TS228KTL-HV/TS250KTL-HV series of PV grid-connected inverters are 1500V three-phase string PV grid-connected inverters. Their main function is to convert the DC energy generated by photovoltaic arrays into AC energy and feed it into the power grid. This series of products possess the advantages of being safe and reliable, grid-connection friendly, highly efficient in power generation, and intelligent in operation and maintenance. They are mainly applicable to scenarios such as deserts, gobi, wastelands, mountainous areas and offshore areas.
Safe and reliable
Grid-friendly
Highly efficient
Intelligent in O&M
Product Advantage
-
-
Grid-Friendly
Specific sub-harmonic suppression technology to effectively reduce current harmonics.
Equipped with SVG function to support the power grid.
Rapid active power response to meet the dispatching requirements of power plants.
-
Safe and Reliable
Superior overall protection performance to adapt to various harsh environments (IP66 protection level, C5 anti-corrosion level).
Intelligent zoned heat exchange and dissipation design.
-
High-Efficiency Power Generation
Intelligent MPPT control strategy with a maximum conversion efficiency of 99.08%.
Multi-channel MPPT, reducing string mismatch effectively.
Excellent temperature derating characteristics to reliably ensure power generation in high-temperature environments.
-
Intelligent O&M
High-precision I-V curve scanning, analysis and diagnosis function.
PID protection function to safeguard the health of modules.
-
-
Grid-Friendly
Specific sub-harmonic suppression technology to effectively reduce current harmonics.
Equipped with SVG function to support the power grid.
Rapid active power response to meet the dispatching requirements of power plants.
-
Safe and Reliable
Superior overall protection performance to adapt to various harsh environments (IP66 protection level, C5 anti-corrosion level).
Intelligent zoned heat exchange and dissipation design.
-
High-Efficiency Power Generation
Intelligent MPPT control strategy with a maximum conversion efficiency of 99.08%.
Multi-channel MPPT, reducing string mismatch effectively.
Excellent temperature derating characteristics to reliably ensure power generation in high-temperature environments.
-
Intelligent O&M
High-precision I-V curve scanning, analysis and diagnosis function.
PID protection function to safeguard the health of modules.
Core Parameters
-
-
TS228/250KTL-HV
Model
-
1500V
Max. Input Voltage
-
30A
Max. Input Current per MPPT
-
24/12
Max. Input Strings/No. of MPPT
-
800Vac，3W+PE
Nominal Output Voltage (V)
-
208kW@50°C
228kW@40°C
250kW@30°CNominal Output Power
-
99.08%
Max. Efficiency
-
1100×700×360
Dimension(W*H*Dmm)
-
110kg
Weight(kg)
-
IP66
IP Rating
-
C5
Corrosion Prevention
-
-
