1~150Mvar
Rated Capacity
-
10~66kV
Rated Voltage
-
50Hz/60Hz
Frequency
-
-40°C~55°C
Ambient Temperature
Product Introduction
TSVG can cover a variety of voltage levels such as 10KV and 35KV. The maximum power of a single machine is 150Mvar, and multiple parallel expansion is supported to achieve greater capacity. With the advantages of high reliability, low loss, grid friendly and environment friendly, it can complete accurate dynamic control of voltage, reactive power and power factor. TSVG has shipped more than 55Gvar worldwide and has successfully guaranteed the smooth operation of thousands of power stations.
Product Advantage
-
-
High Reliability
Control and protection system redundancy.
Online failure without shutdown.
Three levels of protection.
-
Low Loss
Frequency conversion modulation.
"Zero" power operation.
-
Grid Friendly
Weak grid adaptability.
Multi-dimensional compensation.
Zero voltage ride through.
-
Environmentally Friendly
Customized design for extreme environments.
Efficient and energy-saving module design.
-
-
High Reliability
Control and protection system redundancy.
Online failure without shutdown.
Three levels of protection.
-
Low Loss
Frequency conversion modulation.
"Zero" power operation.
-
Grid Friendly
Weak grid adaptability.
Multi-dimensional compensation.
Zero voltage ride through.
-
Environmentally Friendly
Customized design for extreme environments.
Efficient and energy-saving module design.
Core Parameters
-
-
1~150Mvar
Rated Capacity
-
10-66kV
Rated Voltage
-
5ms
Response Speed
-
2000m，>2000m customized
Altitude
-
-40°C~55°C
Ambient Temperature
-
50Hz/60Hz
Frequency
-
＜0.8%
Avg. Losses
-
N-2
Redundant Design
-
-
