TC3125KFT/TC6250KFT

Download PDF

1500V

Max. Input Voltage
＞99.0%

Max. Efficiency
16/18/20
32/36/40

Number of DC Input
<0.5%In

DC Current Injection

Product Introduction

TC3125KFT/TC6250KFT Inverter Transformer Station integrates 3.125MW series inverter, transformer, RMU, auxiliary panel and other equipment into a standard 40 feet container to convert low-voltage DC power from photovoltaic modules into medium-voltage AC power and feed it into the grid. It provides a highly integrated power conversion and distribution solution for the medium voltage grid-connected scenario of photovoltaic ground power stations.

Download PDF

Product Advantage

- Efficient and Economical

  Match 182/210 photovoltaic module, DC 32/36/40 inputs, support 1.8 DC/AC ratio.
  Max. efficiency >99%, European efficiency >98.7%.
  High capacity, reduce quantity of MV equipment, reduce CAPEX.
- Stable and Reliable

  IP65 protection, C4/C5 anti-corrosion, adaptable to harsh environments.
  Scientific thermal design, and effective cooling to improve performance.
- Integrated and Convenient

  Prefabricated and tested, easy transportation and installation.
  Modular inverter design, easy for O&M replacement and maintenance.
- Supportive to Grid

  Comply with standard IEC 62109-1/-2, EN 50530,IEC 62116, IEC 62910, IEC 60068, IEC 61683, CEA2019.
  SCR - 1.0, Low/high voltage ride through (L/HVRT).
  Active&reactive power and power factor control.

Efficient and Economical

Match 182/210 photovoltaic module, DC 32/36/40 inputs, support 1.8 DC/AC ratio.
Max. efficiency >99%, European efficiency >98.7%.
High capacity, reduce quantity of MV equipment, reduce CAPEX.
Stable and Reliable

IP65 protection, C4/C5 anti-corrosion, adaptable to harsh environments.
Scientific thermal design, and effective cooling to improve performance.
Integrated and Convenient

Prefabricated and tested, easy transportation and installation.
Modular inverter design, easy for O&M replacement and maintenance.
Supportive to Grid

Comply with standard IEC 62109-1/-2, EN 50530,IEC 62116, IEC 62910, IEC 60068, IEC 61683, CEA2019.
SCR - 1.0, Low/high voltage ride through (L/HVRT).
Active&reactive power and power factor control.

Core Parameters

- TC3125KFT/ TC6250KFT

  Model
- Oil-immersed, fullysealed, Dy11
  Oil-immersed, fully sealed, Dy11y11

  Type
- 10KV~35KV/0.63KV
  20KV~35KV/0.63KV-0.63KV

  Nominal voltage
- >99%(standard)
  tier1/ tier2(optional)

  Efficiency
- 2438mm×2896mm×6058mm
  2438mm×2896mm×12192mm

  Dimension(W×H×D)
- IP54

  Protection
- -35°C~60°C(>50°C derating)

  Temperature range
- 0%~100%

  Relative humidity range
- 1500m, Customizable

  Max.operating altitude
- RS485 / Ethernet

  Communication interface
- Modbus-RTU / Modbus-TCP / IEC104

  Communication protocol

TC3125KFT/ TC6250KFT

Model
Oil-immersed, fullysealed, Dy11
Oil-immersed, fully sealed, Dy11y11

Type
10KV~35KV/0.63KV
20KV~35KV/0.63KV-0.63KV

Nominal voltage
>99%(standard)
tier1/ tier2(optional)

Efficiency
2438mm×2896mm×6058mm
2438mm×2896mm×12192mm

Dimension(W×H×D)
IP54

Protection
-35°C~60°C(>50°C derating)

Temperature range
0%~100%

Relative humidity range
1500m, Customizable

Max.operating altitude
RS485 / Ethernet

Communication interface
Modbus-RTU / Modbus-TCP / IEC104

Communication protocol
